Name: SCARA Robot | Industrial
Brand: Variobotic
SKU: RBTX-VAR-0009
Price: 140,970,000.00 IDR
Availability: InStock

fairBanner

CommunityDesignLink

showCommunityLink

rbtxpert-button-de

rbtxpert-button-us

<p>The DOBOT M1 Pro SCARA robot is fast, precise and reliable. Whether for pick and place, dispensing, separating or sorting or in a laboratory, with its four axes it is used in a wide variety of applications. With short payback times, it offers small and medium-sized businesses in particular the possibility of cost-efficient automation. With the integrated control system in the robot base, it is easy to use and offers fast commissioning.</p>

The weight of an end effector will decrease the available payload of your robot.

SCARA Robot | Industrial

Robot

CAD file

Data sheet

Vendor link

Download DobotStudio Pro

4Rj2Ri32sINBKwJaNiAUUn

The field of application of the M1 PRO is wide-ranging. In addition to sorting and separating, the DOBOT M1 PRO can, for example, load pallets or perform for example, load pallets or perform laboratory and quality tasks. In addition to a vacuum suction cup or a pneumatic gripper, any individual tool can be attached in order to implement several automation solutions several automation solutions with one and the same robot. The inputs and outputs are can also be expanded with additional I/Os using an add-on module.

The DOBOT M1 PRO is controlled via the user-friendly and license-free DobotStudio Pro software. It enables quick commissioning, even without prior knowledge. The DOBOT M1 PRO can be programmed via Python or Java in script mode. In addition, the software also supports control via Teaching & Playback and the DOBOTBlock graphical development environment, in which prefabricated programming blocks are arranged logically.

Control/Software

Camera-assisted component separation

Separação de componentes assistida por câmera

Componentscheiding met camera

Kameraunterstützte Bauteilevereinzelung

相機輔助元件分離

Separazione assistita dei componenti con visione

摄像设备辅助机器人分离组件

Bin-Picking

料框抓取

箱式拾取

Grijpen in de kist

Collecte de bac

빈 피킹(Bin-picking)

ビン詰め作業

Podnoszenie-Pojemników

bin-picking

Example of a complete solution from Variobotic

In this application example from the "bin picking" sector, several work steps could be automated with an intelligent solution.

The supply hopper drops the components onto the "Varioshaker 270", which then separates them using vibration. The vision system then recognizes the individual parts and transmits this data to the Dobot. With the help of an EGP end effector, the Dobot picks up the components for further processing.

With the help of the various robot components, an intelligent solution was created.

Produktion

Manufacturing

Production

製造業

Fabricação

Productie

Produkcja

การผลิต

制造业

Üretim

제조

Produzione

manufacturing

VarioFeed Advanced - All-in-One Paket zur flexiblen Vereinzelung von Schüttgut

VarioFeed Advanced - All-in-one package for flexible separation of bulk materials

VarioFeed 進階 - 多合一包裝，用於靈活分離散裝材料

VarioFeed Advanced - Alles-in-één pakket voor flexibele scheiding van bulkmaterialen

VarioFeed Advanced - 灵活分离散装物料的一体化解决方案

Pick & Place

Pick-and-Place

Al ve yerleştir

拾取&放置

픽 앤 플레이스

ピック&プレース

Pick &amp: Place

取放 (揀選 & 放置)

Pick and place

หยิบและวาง

pick-n-place

The All-in-One Package for optimal part separation

The VarioFeed from Variobotic enables a simple and flexible feeding solution that is also cost-effective. The Advanced combination consists of the VarioShaker 270 component separator, the DOBOT M1 (Pro) robot, as well as a feeding system and an image processing solution. The DOBOT M1 industrial robot impresses in the solution with high accuracy (+- 0.02 mm) and, together with the VarioShaker 270, achieves up to 20 picks/min. The application is characterized by simple operation and fast commissioning. The all-in-one package allows various work steps to be automated, such as in the pick and place area.

Automated ball bearing assembly

Automatisierte Kugellagermontage

Spritzguss

Injection molding

注塑成型

injection-molding

In this video, we present an advanced solution for the automated assembly of ball bearings in production. The setup of the gantry system and the integration of the Epson Scara are shown, as well as the operation of the rotary conveyor and the Variobotic shaker cameras for precise detection and positioning of the ball bearing components. The Schunk and Schmalz grippers are demonstrated in action, handling the ball bearings safely and efficiently. The step feeder supports the process with its precise conveying technique, ensuring that the entire system operates smoothly and efficiently thanks to reliable power and data transmission. The benefits of this solution include increased production speed, reduced scrap, and improved workplace safety. Additionally, a low footprint is ensured, facilitating integration into various production environments.

Pick and Place Kundenanwendung mit EPSON Scara T3

Pick and Place customer application with EPSON Scara T3

Customer Tests

Testen door klanten

Tests clients

Müşteri Testleri

客户测试

Testes de clientes

Testy klienta

การทดสอบของลูกค้า

客戶測試

Kundentests

Test dei clienti

customer-tests

Tes Pelanggan

总览

In this customer's application, plastic parts had to be reliably sorted into a fixture. Due to the tight tolerances, the decision was made to use the T3 Scara robot from EPSON.

With a repeat accuracy of approx. 0.02 mm, the high precision requirements were easily met. The versatile industrial robot offers an inexpensive entry-level solution for production lines.

With a payload of 3 kg, 400 mm reach and 0.02 mm repeatability, the compact T3 robot is ideal for simple pick-and-place applications.

Automated packaging of barbecue lighter with a SCARA robot

Automatisiertes Verpacken von Grillanzündern mit einem SCARA Roboter

In this video, we show a customer test in the igus Customer Testing Area (CTA). The application involves the packaging of barbecue lighters using the epson T3 Scara robot.

The SCARA robots from EPSON are particularly suitable for high-speed applications with high precision requirements. The low cost price compared to the market leads to a fast ROI and allows the investment to be amortized within a short period of time.

Verpackung

Packaging

包装機械

包装业

Verpakkingsindustrie

포장 산업

包裝業

Przemysł pakujący

Emballage

Empaquetado y embalaje

packaging

Separação de componentes baseada em câmera com sistema de câmera 2D e placa vibratória

Camera-based component separation with 2D camera system and vibration plate

Op camera gebaseerde componentenscheiding met 2D-camerasysteem en trilplaat

Separazione dei componenti tramite visione impiegando telecamere 2D e tavola vibrante

Kamerabasierte Bauteilevereinzelung mit 2D Kamerasystem und Vibrationsplatte

Handhabung

Material handling

Manuseio de materiais

Malzeme taşıma

Przeładunek materiałów

Manipulación de materiales

倉儲物流

物料搬运

Materiaal handling

ระบบจัดการสินค้า

물류 산업

Movimentazione dei materiali

マテリアルハンドリング

Manipulation

material-handling

This video highlights a customer test conducted in the igus Customer Testing Area (CTA), where metal parts are isolated using a Varioshaker. Subsequently, the contours of the parts are teched into an ifm 2D camera for precise detection and analysis.

 The test demonstrates the efficiency of the Varioshaker in isolating individual parts and the capability of the ifm 2D camera to identify these parts for quality control or automated processes.

The video impressively showcases how modern technologies are applied in automation technology to optimize processes and ensure product quality.

igus SCARA Pick and Place application

igus SCARA Pick and Place Anwendung

igus SCARA Pick and Place toepassing

Applicazione igus SCARA pick & place

Aplicação SCARA Pick and Place da igus

This video presents a customer test where small metal plates are handled automatically. The process demonstrates how the plates are precisely and efficiently transferred from a device into a box. This is made possible by the use of an igus SCARA robot, a collaborative robot known for its flexibility and user-friendliness.The robot is equipped with an egp 25 end-effector, a gripper designed specifically for handling small and lightweight objects.

The combination of the SCARA robot and the egp 25 end-effector showcases an innovative solution for the automation of assembly processes and illustrates the potential for improved production speed and precision.

Conveyor belt picking with igus SCARA

Transportband verzamelen met igus SCARA

Förderband Picking mit igus SCARA

Presa da nastro trasportatore con SCARA igus

使用易格斯SCARA进行传送带分拣

Coleta de correia transportadora com SCARA da igus

The video showcases an automated pick-and-place system designed for a customer test. It features an igus SCARA robot equipped with a high-precision Schunk gripper, positioned above a conveyor belt transporting various items.

The igus SCARA robot is noted for its rapid and accurate movements, ideal for handling small to medium-sized objects. The Schunk gripper, renowned for its reliability and fine control, can securely grasp a wide range of parts with different shapes and surfaces.

During operation, the robot picks individual items from the moving conveyor belt and places them precisely in a predefined location. This process, known as pick-and-place, is a critical step in many manufacturing and packaging processes.

The video demonstrates the system’s smooth operation and high repeatability in part placement, crucial for customer satisfaction and the efficiency of the test. It also highlights the system’s easy integration into existing production lines and its adaptability to various applications.
